Bulkhead push-in fitting female thread 1/8 NPT for tubing O.D. 3/16" QSSF-1/8-3/16-U - Festo 153768

Festo ✓ Original product Brand new

The Festo bulkhead push-in fitting QSSF-1/8-3/16-U passes tubing with O.D. 3/16" through a wall or panel and provides a female thread 1/8 NPT on the other side. With -0.95 to 10 bar operating pressure it also suits vacuum lines, permitted ambient temperature is -10 to 60 °C.

Net
€5.20
excl. VAT
Item FES-153768
Manufacturer no. QSSF-1/8-3/16-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo bulkhead push-in fitting QSSF-1/8-3/16-U passes tubing with O. D. 3/16" through a wall or panel and provides a female thread 1/8 NPT on the other side. Following the push-pull principle, the tube (3/16") is simply pushed in and released again via the grey release ring.

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range permitted from -10 to 60 °C
  • Flow nominal size 4 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops
  • Mounting External hex 11/16

Applications

For control cabinets, machine guards and housing walls through which a line with tubing O. D. 3/16" is routed. Operating medium is compressed air to ISO 8573-1:2010 [7:-:-], nominal size 4 mm. Lubricated compressed air is also permitted. Nickel-plated housing, RoHS compliant.

Technical data

FeatureValue
TypeQSSF-1/8-3/16-U
Festo part number153768
SizeStandard
Nominal size4 mm
Type of seal on screwed plugCoating
Mounting positionAny
DesignBulkhead
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight28 g
Type of mountingExternal hex 11/16
Pneumatic connection, port 1Female thread 1/8 NPT
Pneumatic connection, port 2For tubing outside diameter of 3/16"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingnickel-plated
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.032 kg
ManufacturerFesto
Hersteller-NrQSSF-1/8-3/16-U
EAN4052568310509
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
BauformSchott
ThreadNPT 1/8
Nominal size DN [mm]4
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSSF
Betriebsdruck max [bar]10
Pneumatic connectionNPT 1/8
Temperaturbereich-10-60 °C
Temperature (max.)60
