Bulkhead push-in fitting female thread 1/4 NPT for tubing O.D. 1/4" QSSF-1/4-1/4-U - Festo 153771
The Festo bulkhead push-in fitting QSSF-1/4-1/4-U passes tubing with O.D. 1/4" through a wall or panel and provides a female thread 1/4 NPT on the other side. Operating pressure is -0.95 to 10 bar, ambient temperature -10 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo bulkhead push-in fitting QSSF-1/4-1/4-U passes tubing with O. D. 1/4" through a wall or panel and provides a female thread 1/4 NPT on the other side. The 1/4" tube locks when pushed in and can be pulled out again after pressing the grey release ring.
Benefits
- Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
- Temperature range usable at -10 to 60 °C
- Flow free cross-section with nominal size 5.3 mm
- Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
- PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops
- Mounting External hex 11/16
Applications
For control cabinets, machine guards and housing walls through which a line with tubing O. D. 1/4" is routed. Designed for compressed air to ISO 8573-1:2010 [7:-:-] at 5.3 mm nominal size. Lubricated compressed air is also permitted. The body is nickel-plated.
Technical data
| Feature | Value |
|---|---|
| Type | QSSF-1/4-1/4-U |
| Festo part number | 153771 |
| Size | Standard |
| Nominal size | 5.3 mm |
| Type of seal on screwed plug | Coating |
| Mounting position | Any |
| Design | Bulkhead |
| Construction | Push-pull principle |
| Operating pressure complete temperature range | -0.95 to 10 bar |
| Maritime classification | See certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 to 60 °C |
| Product weight | 29 g |
| Type of mounting | External hex 11/16 |
| Pneumatic connection, port 1 | Female thread 1/4 NPT |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/4" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | nickel-plated |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Weight | 0.028 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QSSF-1/4-1/4-U |
| EAN | 4052568310530 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Schott |
| Thread | NPT 1/4 IG |
| Nominal size DN [mm] | 5,3 |
| Size BG | Standard |
| Seal material | NBR |
| Medium | Compressed air |
| Series | QSSF |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/4 IG |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
