Bulkhead push-in fitting female thread 1/2 NPT for tubing O.D. 1/2" QSSF-1/2-1/2-U - Festo 153778

Festo ✓ Original product Brand new

The Festo bulkhead push-in fitting QSSF-1/2-1/2-U passes tubing with O.D. 1/2" through a wall or panel and provides a female thread 1/2 NPT on the other side. Operating pressure is -0.95 to 10 bar, ambient temperature -10 to 60 °C.

Net
€12.09
excl. VAT
Item FES-153778
Manufacturer no. QSSF-1/2-1/2-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo bulkhead push-in fitting QSSF-1/2-1/2-U passes tubing with O. D. 1/2" through a wall or panel and provides a female thread 1/2 NPT on the other side. Tool-free installation: push in the 1/2" tube, press the grey release ring to release it (push-pull principle).

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range permitted from -10 to 60 °C
  • Flow nominal size 11 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops
  • Mounting External hexagon 1

Applications

Intended for feed-throughs in sheet-metal walls and control cabinets with lines of tubing O. D. 1/2". Permitted medium: compressed air to ISO 8573-1:2010 [7:-:-], nominal size 11 mm. Lubricated operation is possible. Nickel-plated housing, RoHS compliant.

Technical data

FeatureValue
TypeQSSF-1/2-1/2-U
Festo part number153778
SizeStandard
Nominal size11 mm
Type of seal on screwed plugCoating
Mounting positionAny
DesignBulkhead
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight70 g
Type of mountingExternal hexagon 1
Pneumatic connection, port 1Female thread 1/2 NPT
Pneumatic connection, port 2For tubing outside diameter of 1/2"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingnickel-plated
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.085 kg
ManufacturerFesto
Hersteller-NrQSSF-1/2-1/2-U
EAN4052568310608
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
BauformSchott
ThreadNPT 1/2
Nominal size DN [mm]11
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSSF
Betriebsdruck max [bar]10
Pneumatic connectionNPT 1/2 IG
Temperaturbereich-10-60 °C
Temperature (max.)60
