Cartridge 14 mm for tubing OD 1/4" QSP14-1/4-U - Festo 172985

Festo ✓ Original product Brand new

QSP14-1/4-U is a cartridge for 14 mm seats into which tubing with an OD of 1/4" is pushed directly. The QSP14-1/4-U is specified for -0.95 to 10 bar operating pressure and -5 to 60 °C ambient temperature. The tube is pushed in and released again via the release ring.

Net
€4.00
excl. VAT
Item FES-172985
Manufacturer no. QSP14-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

QSP14-1/4-U is a cartridge for 14 mm seats into which tubing with an OD of 1/4" is pushed directly. The QSP14-1/4-U is specified for -0.95 to 10 bar operating pressure and -5 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Mini sizeproduct weight 12.1 g
  • Ambient temperature -5 to 60 °C
  • Push-pull principle push the tube in, press the grey release ring to remove it
  • Tubing seal made of NBR
  • LABS (PWIS) conformity to VDMA24364-B1/B2-L

Applications

QSP14-1/4-U is intended for valves, valve terminals and devices with a cartridge seat. The QSP14-1/4-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible.

Technical data

FeatureValue
TypeQSP14-1/4-U
Festo part number172985
SizeMini
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-5 to 60 °C
Product weight12.1 g
Mounting typeMounting pin
Pneumatic connection 1Cartridge 14 mm
Pneumatic connection 2For tubing OD 1/4"
Release ring colourGrey
Material noteRoHS compliant
Housing materialNickel-plated
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
Weight0.012 kg
ManufacturerFesto
Hersteller-NrQSP14-1/4-U
EAN4052568313050
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Bauformgerade Form
Size BGMini
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]10
Temperaturbereich-5-60 °C
Temperature (max.)60
