Self-sealing push-in fitting 10-32 UNF-2A for 1/4" tubing QSMK-10-32-UNF-1/4-U - Festo 190707

Festo ✓ Original product Brand new

Screw into 10-32 UNF-2A, push in 1/4" OD tubing: the Festo QSMK-10-32-UNF-1/4-U joins both using the push-pull principle. Pressure range -0.95 to 10 bar, ambient temperature -10 to 60 °C. The self-sealing function closes the port as soon as the tubing is pulled out.

Net
€10.17
excl. VAT
Item FES-190707
Manufacturer no. QSMK-10-32-UNF-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Up to 10 bar operating pressure and vacuum down to -0.95 bar: the Festo QSMK-10-32-UNF-1/4-U is designed for a 10-32 UNF-2A thread and 1/4" tubing. Permissible ambient temperature -10 to 60 °C.

Benefits

  • Self-sealing for 1/4" OD tubing: without tubing the port stays closed
  • Operating pressure -0.95 to 10 bar across the full temperature range
  • Threaded stud sealed by sealing ring, maximum tightening torque 1.5 Nm
  • Corrosion resistance class CRC 1, tubing clamp segment in stainless steel
  • For compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible
  • Ambient temperature -10 to 60 °C

Applications

Size Mini, matching 1/4" OD tubing. The QSMK-10-32-UNF-1/4-U is tightened via an external hexagon 7/16. Any mounting position is allowed. Typical locations for the QSMK-10-32-UNF-1/4-U with 10-32 UNF-2A are valves, cylinders and service units.

Technical data

FeatureValue
TypeQSMK-10-32-UNF-1/4-U
Festo part number190707
SizeMini
Nominal size1.7 mm
Seal type on threaded studSealing ring
Mounting positionAny
DesignStraight
Design structurePush-pull principle
Operating pressure across the full temperature range-0.95 to 10 bar
Marine classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
PWIS (LABS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Maximum tightening torque1.5 Nm
Mounting typeExternal hexagon 7/16
Pneumatic connection 1Male thread 10-32 UNF-2A
Pneumatic connection 2For tubing OD 1/4"
Release ring colourGrey
Note on materialsRoHS compliant
Material housingNickel-plated brass
Material release ringPOM
Material tubing sealNBR
Material tubing clamp segmentHigh-alloy stainless steel
Weight19 g
ManufacturerFesto
Hersteller-NrQSMK-10-32-UNF-1/4-U
EAN4052568323127
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialBrass
ThreadUNF 10-32
Nominal size DN [mm]1,7
Size BGMini
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich-10-60 °C
Temperature (max.)60
