Push-in L-connector with plug sleeve Ø 3/8" for tubing O.D. 3/8" QSL-3/8H-U - Festo 153656

Festo ✓ Original product Brand new

Via its plug sleeve Ø 3/8", the Festo push-in L-connector QSL-3/8H-U sits directly in the push-in port and serves one tube at 90° with O.D. 3/8". Operating pressure is -0.95 to 10 bar, ambient temperature -10 to 60 °C.

Net
€5.42
excl. VAT
Item FES-153656
Manufacturer no. QSL-3/8H-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Via its plug sleeve Ø 3/8", the Festo push-in L-connector QSL-3/8H-U sits directly in the push-in port and serves one tube at 90° with O. D. 3/8". Following the push-pull principle, the tube (3/8") is simply pushed in and released again via the grey release ring.

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range -10 to 60 °C ambient temperature
  • Flow free cross-section with nominal size 5.7 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops

Applications

Where there is little room next to the port, the elbow leads the tubing (tubing O. D. 3/8") away without kinking. Designed for compressed air to ISO 8573-1:2010 [7:-:-] at 5.7 mm nominal size. Lubricated operation is possible. The body is made of PBT.

Technical data

FeatureValue
TypeQSL-3/8H-U
Festo part number153656
SizeStandard
Nominal size5.7 mm
Mounting positionAny
DesignL-shape
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight9.5 g
Pneumatic connection, port 1Push-in sleeve Ø 3/8"
Pneumatic connection, port 2For tubing outside diameter of 3/8"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingPBT
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.01 kg
ManufacturerFesto
Hersteller-NrQSL-3/8H-U
EAN4052568310431
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformL-Form
Nominal size DN [mm]5,7
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSL
Betriebsdruck max [bar]10
Temperaturbereich-10-60 °C
Temperature (max.)60
