Push-in cap for tubing O.D. 1/4", -0.95 to 10 bar QSC-1/4-U - Festo 153830

Festo ✓ Original product Brand new

With the Festo push-in cap QSC-1/4-U, an open tube with O.D. 1/4" is reliably sealed. With -0.95 to 10 bar operating pressure it also suits vacuum lines, permitted ambient temperature is -10 to 60 °C.

Net
€1.63
excl. VAT
Item FES-153830
Manufacturer no. QSC-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the Festo push-in cap QSC-1/4-U, an open tube with O. D. 1/4" is reliably sealed. Following the push-pull principle, the tube (1/4") is simply pushed in and released again via the grey release ring.

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range usable at -10 to 60 °C
  • Flow free cross-section with nominal size 3.8 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops

Applications

Handy during commissioning, testing and conversion to close lines with O. D. 1/4" temporarily. Permitted medium: compressed air to ISO 8573-1:2010 [7:-:-], nominal size 3.8 mm. Lubricated operation is possible. Housing in PBT, RoHS compliant.

Technical data

FeatureValue
TypeQSC-1/4-U
Festo part number153830
SizeStandard
Nominal size3.8 mm
Tubing insertion depth17 mm
Mounting positionAny
DesignBlanking plug
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight3.3 g
Pneumatic connection, port 1For tubing O. D. 1/4"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingPBT
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.003 kg
ManufacturerFesto
Hersteller-NrQSC-1/4-U
EAN4052568311018
Zolltarifnummer39269097
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformBlindstopfen
Nominal size DN [mm]3,8
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSC
Betriebsdruck max [bar]10
Temperaturbereich-10-60 °C
Temperature (max.)60
