Push-in cap for tubing O.D. 1/2", -0.95 to 10 bar QSC-1/2-U - Festo 153833

Festo ✓ Original product Brand new

With the Festo push-in cap QSC-1/2-U, an open tube with O.D. 1/2" is reliably sealed. Operating pressure is -0.95 to 10 bar, ambient temperature -10 to 60 °C. The 1/2" tube locks when pushed in and can be pulled out again after pressing the grey release ring.

Net
€2.25
excl. VAT
Item FES-153833
Manufacturer no. QSC-1/2-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the Festo push-in cap QSC-1/2-U, an open tube with O. D. 1/2" is reliably sealed. The 1/2" tube locks when pushed in and can be pulled out again after pressing the grey release ring.

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range permitted from -10 to 60 °C
  • Flow nominal size 7.8 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops

Applications

Useful for sealing spare lines with O. D. 1/2". Designed for compressed air to ISO 8573-1:2010 [7:-:-] at 7.8 mm nominal size. Lubricated compressed air is also permitted. The body is made of PBT.

Technical data

FeatureValue
TypeQSC-1/2-U
Festo part number153833
SizeStandard
Nominal size7.8 mm
Tubing insertion depth23.2 mm
Mounting positionAny
DesignBlanking plug
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight12 g
Pneumatic connection, port 1For tubing O. D. 1/2"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingPBT
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.011 kg
ManufacturerFesto
Hersteller-NrQSC-1/2-U
EAN4052568311049
Zolltarifnummer39269097
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformBlindstopfen
Nominal size DN [mm]7,8
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSC
Betriebsdruck max [bar]10
Temperaturbereich-10-60 °C
Temperature (max.)60
