Push-in T-fitting with male thread 1/4 NPT for tubing O.D. 5/16" QBTL-1/4-5/16-U - Festo 564717
The push-in T-fitting QBTL-1/4-5/16-U combines male thread 1/4 NPT with a connection for tubing O.D. 5/16". The housing is made of PBT, the nominal width is 5.994 mm and the permitted operating pressure -0.95 to 10 bar (vacuum included). Permitted ambient temperature: 0 to 60 °C. RoHS compliant.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The push-in T-fitting QBTL-1/4-5/16-U combines male thread 1/4 NPT with a connection for tubing O. D. 5/16". The nominal width is 5.994 mm and the operating pressure -0.95 to 10 bar.
Benefits
- Male thread 1/4 NPT with sealing coating
- Connection for tubing O. D. 5/16"
- Nominal width 5.994 mm
- Operating pressure -0.95 to 10 bar, vacuum included
- Housing in PBT, corrosion resistance class 1
- Tubing released by the push-pull principle via the release ring
Applications
The QBTL-1/4-5/16-U is suitable for working and control lines with O. D. 5/16", connected via male thread 1/4 NPT.
Technical data
| Feature | Value |
|---|---|
| Type | QBTL-1/4-5/16-U |
| Festo part number | 564717 |
| Size | standard |
| Nominal width | 5.994 mm |
| Seal type on screw-in stud | coating |
| Mounting position | any |
| Design | L-shape, additional push-in connection lengthwise |
| Construction | push-pull principle |
| Operating pressure, full temperature range | -0.95 to 10 bar |
| Operating medium | compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | lubricated operation possible |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Product weight | 26.394 g |
| Mounting type | external hex 9/16 |
| Pneumatic connection 1 | male thread 1/4 NPT |
| Pneumatic connection 2 | for tubing O. D. 5/16" |
| Release ring colour | grey |
| Material note | RoHS compliant |
| Housing material | PBT |
| Thread seal material | PTFE |
| Release ring material | POM |
| Tubing seal material | NBR |
| Tubing clamp segment material | high-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | QBTL-1/4-5/16-U |
| EAN | 4052568366032 |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Thread | NPT 1/4 |
| Seal material | NBR, PTFE |
| Medium | Compressed air |
| Thread type | External thread |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/4 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
