T-shaped multiple distributor, tubing OD 3/8 in to tubing OD 1/4 in QBT3-3/8T-1/4-U - Festo 564795
The T-shaped QBT3-3/8T-1/4-U multiple distributor branches a tubing line using push-in connections. Inlet tubing OD 3/8 in, outlets tubing OD 1/4 in. Materials: housing made of PBT, release ring made of POM, tube seal made of NBR.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The T-shaped QBT3-3/8T-1/4-U multiple distributor branches a tubing line using push-in connections. Usable from vacuum (-0.95 bar) up to 10 bar.
Benefits
- Push-in connections based on the push-pull principle, insert the tubing and release it via the release ring
- Operating pressure -0.95 to 10 bar, vacuum-capable
- Nominal width 5.004 mm
- Ambient temperature 0 to 60 °C
- Housing made of PBT
- Corrosion resistance class CRC 1 for low corrosion stress
Applications
For compressed-air distribution at valve terminals, cylinder groups and blow nozzles where several consumers are supplied from one port.
Technical data
| Feature | Value |
|---|---|
| Type | QBT3-3/8T-1/4-U |
| Festo part number | 564795 |
| Product type | Multiple distributor |
| Size | Standard |
| Nominal width | 5.004 mm |
| Mounting position | any |
| Design shape | T-shape |
| Design | push-pull principle |
| Operating pressure across the full temperature range | -0.95 to 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS (LABS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Pneumatic connection 1 | For tubing OD 3/8 in |
| Pneumatic connection 2 | For tubing OD 1/4 in |
| Colour of release ring | grey |
| Material note | RoHS compliant |
| Housing material | PBT |
| Release ring material | POM |
| Tube seal material | NBR |
| Tube clamping segment material | High-alloy stainless steel |
| Weight | 0.023 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QBT3-3/8T-1/4-U |
| EAN | 4052568366797 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Seal material | NBR |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
