T-shaped multiple distributor, tubing OD 1/4 in to tubing OD 5/32 in QBT3-1/4T-5/32-U - Festo 564791

Festo ✓ Original product Brand new

The T-shaped QBT3-1/4T-5/32-U multiple distributor branches a tubing line using push-in connections. The inlet takes tubing OD 1/4 in, the outlets tubing OD 5/32 in. Usable from vacuum (-0.95 bar) up to 10 bar.

Net
€6.42
excl. VAT
Item FES-564791
Manufacturer no. QBT3-1/4T-5/32-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The T-shaped QBT3-1/4T-5/32-U multiple distributor branches a tubing line using push-in connections. Usable from vacuum (-0.95 bar) up to 10 bar.

Benefits

  • Push-in connections based on the push-pull principle, insert the tubing and release it via the release ring
  • Operating pressure -0.95 to 10 bar, vacuum-capable
  • Nominal width 3.2 mm
  • Ambient temperature 0 to 60 °C
  • Housing made of PBT
  • Corrosion resistance class CRC 1 for low corrosion stress

Applications

Typical in control cabinets and machine building when lines have to be branched in a tight space.

Technical data

FeatureValue
TypeQBT3-1/4T-5/32-U
Festo part number564791
Product typeMultiple distributor
SizeStandard
Nominal width3.2 mm
Mounting positionany
Design shapeT-shape
Designpush-pull principle
Operating pressure across the full temperature range-0.95 to 10 bar
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
PWIS (LABS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Pneumatic connection 1For tubing OD 1/4 in
Pneumatic connection 2For tubing OD 5/32 in
Colour of release ringgrey
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tube seal materialNBR
Tube clamping segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQBT3-1/4T-5/32-U
EAN4052568366759
Zolltarifnummer90330090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
Nominal size DN [mm]3,2
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
