Push-in T-fitting QBMTL-10-32-UNF-1/8-U - Festo 572295
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Size | Mini |
|---|---|
| Nominal size | 2.489 mm |
| Type of seal on screwed plug | Sealing ring |
| Mounting position | Any |
| Design | T-shape, additional push-in connector, lengthwise |
| Size of pack | 10 |
| Operating pressure complete temperature range | -0.95 ... 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 ... 60 °C |
| Max. tightening torque | 1.5 Nm |
| Product weight | 2.013 g |
| Type of mounting | External hex 5/16 |
| Pneumatic connection, port 1 | Male thread 10-32 UNF-2A |
| Pneumatic connection, port 2 | For tubing O.D. 1/8" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | QBMTL-10-32-UNF-1/8-U |
| EAN | 4052568374693 |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
