Push-in T-fitting male thread 10-32 UNF-2A for tubing outside diameter of 1/4" QBMTL-10-32-UNF-1/4-U - Festo 573071
The Festo push-in T-fitting QBMTL-10-32-UNF-1/4-U splits the air flow at the threaded port into two tubes. Relevant for selection: port 1 male thread 10-32 UNF-2A and port 2 for tubing outside diameter of 1/4". Also documented: operating pressure -0.95 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo push-in T-fitting QBMTL-10-32-UNF-1/4-U splits the air flow at the threaded port into two tubes. Relevant for selection: port 1 male thread 10-32 UNF-2A and port 2 for tubing outside diameter of 1/4".
Benefits
- Temperature range: usable from 0 to 60 °C
- Pressure and vacuum: -0.95 to 10 bar, so also suitable for vacuum lines
- Corrosion protection: corrosion resistance class CRC 1 (low corrosion stress)
- Installation: tightening torque 1.5 Nm
- Flow: nominal size 2.489 mm
- PWIS: PWIS conformity VDMA24364 zone III
Applications
Suited to compressed air installations in machine building, especially with inch threads and inch tubing. Lubricated operation is possible. The permitted temperature range is 0 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | QBMTL-10-32-UNF-1/4-U |
| Festo part number | 573071 |
| Size | Mini |
| Nominal size | 2.489 mm |
| Type of seal on screwed plug | Sealing ring |
| Mounting position | Any |
| Design | T-shape, additional push-in connector, lengthwise |
| Construction | Push-pull principle |
| Operating pressure complete temperature range | -0.95 to 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Max. tightening torque | 1.5 Nm |
| Product weight | 10.008 g |
| Type of mounting | External hex 5/16 |
| Pneumatic connection, port 1 | Male thread 10-32 UNF-2A |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/4" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | QBMTL-10-32-UNF-1/4-U |
| EAN | 4052568376055 |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Bauform | L-Form, zusätzlicher Steckanschluss längs |
| Thread | UNF 10-32 |
| Seal material | NBR |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
