Straight push-in fitting with female thread 10-32 UNF-2B to tubing OD 5/32", PBT QBMF-10-32-UNF-5/32-U - Festo 572283

Festo ✓ Original product Brand new

QBMF-10-32-UNF-5/32-U is the straight transition from a 10-32 UNF-2B thread to tubing with an OD of 5/32". The QBMF-10-32-UNF-5/32-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature. The tube is pushed in and released again via the release ring.

Net
€2.68
excl. VAT
Item FES-572283
Manufacturer no. QBMF-10-32-UNF-5/32-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

QBMF-10-32-UNF-5/32-U is the straight transition from a 10-32 UNF-2B thread to tubing with an OD of 5/32". The QBMF-10-32-UNF-5/32-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Mini sizeproduct weight 4.99 g
  • Ambient temperature 0 to 60 °C
  • Push-pull principle push the tube in, press the grey release ring to remove it
  • Housing made of PBTcorrosion resistance class CRC 1
  • Tubing seal made of NBR

Applications

Typical locations for the QBMF-10-32-UNF-5/32-U are valves, cylinders and service units with a 10-32 UNF-2B port. Approved medium for the QBMF-10-32-UNF-5/32-U: compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQBMF-10-32-UNF-5/32-U
Festo part number572283
SizeMini
Nominal width2.997 mm
Seal type on screw-in studSealing ring
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Max. tightening torque1.5 Nm
Product weight4.99 g
Mounting typeExternal hex 5/16
Pneumatic connection 1Female thread 10-32 UNF-2B
Pneumatic connection 2For tubing OD 5/32"
Release ring colourGrey
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQBMF-10-32-UNF-5/32-U
EAN4052568374594
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
Bauformgerade Form
ThreadUNF 10-32
Size BGMini
Seal materialNBR
MediumCompressed air
Thread typeInternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
