Push-in L-fitting female thread 1/4 NPT for tubing outside diameter of 3/8" QBLF-1/4-3/8-U - Festo 564661
The Festo push-in L-fitting QBLF-1/4-3/8-U turns the tubing through 90° directly at the threaded port. Relevant for selection: port 1 female thread 1/4 NPT and port 2 for tubing outside diameter of 3/8". Further: operating pressure -0.95 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo push-in L-fitting QBLF-1/4-3/8-U turns the tubing through 90° directly at the threaded port. Relevant for selection: port 1 female thread 1/4 NPT and port 2 for tubing outside diameter of 3/8".
Benefits
- Temperature range: usable from 0 to 60 °C
- Pressure and vacuum: -0.95 to 10 bar, so also suitable for vacuum lines
- Corrosion protection: corrosion resistance class CRC 1 (low corrosion stress)
- Flow: nominal size 7.01 mm
- PWIS: PWIS conformity VDMA24364 zone III
Applications
For compressed air lines at valves, cylinders and service units, especially with inch threads and inch tubing. Lubricated operation is possible. The permitted temperature range is 0 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | QBLF-1/4-3/8-U |
| Festo part number | 564661 |
| Size | Standard |
| Nominal size | 7.01 mm |
| Type of seal on screwed plug | Coating |
| Mounting position | Any |
| Design | L-shape |
| Construction | Push-pull principle |
| Operating pressure complete temperature range | -0.95 to 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Product weight | 32.206 g |
| Type of mounting | External hex 11/16 |
| Pneumatic connection, port 1 | Female thread 1/4 NPT |
| Pneumatic connection, port 2 | For tubing outside diameter of 3/8" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material thread seal | PTFE |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | QBLF-1/4-3/8-U |
| EAN | 4052568365479 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Bauform | L-Form |
| Thread | NPT 1/4 IG |
| Seal material | NBR |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
