Push-in L-connector QBL-5/16T-U - Festo 564763
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Size | Standard |
|---|---|
| Nominal size | 7.01 mm |
| Mounting position | Any |
| Design | L-shape |
| Size of pack | 10 |
| Operating pressure complete temperature range | -0.95 ... 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 ... 60 °C |
| Product weight | 9.412 g |
| Pneumatic connection, port 1 | For tubing O.D. 5/16" |
| Pneumatic connection, port 2 | For tubing outside diameter of 5/16" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Weight | 0.008 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QBL-5/16T-U |
| EAN | 4052568366490 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
