Push-in L-fitting 3/8 NPT to tubing OD 3/16", PBT QBL-3/8-3/16-U - Festo 567763

Festo ✓ Original product Brand new

Where space next to the port is tight, the push-in L-fitting QBL-3/8-3/16-U connects tubing with an OD of 3/16" to the 3/8 NPT thread at an angle. The QBL-3/8-3/16-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Net
€3.45
excl. VAT
Item FES-567763
Manufacturer no. QBL-3/8-3/16-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Where space next to the port is tight, the push-in L-fitting QBL-3/8-3/16-U connects tubing with an OD of 3/16" to the 3/8 NPT thread at an angle. The QBL-3/8-3/16-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Push-pull principle push the tube in, press the grey release ring to remove it
  • Housing made of PBTcorrosion resistance class CRC 1
  • Tubing seal made of NBR
  • Coated screw-in stud made of PTFE
  • LABS (PWIS) conformity to VDMA24364 zone III

Applications

The QBL-3/8-3/16-U connects tubing lines to valves, actuators and manifolds with a 3/8 NPT thread. Approved medium for the QBL-3/8-3/16-U: compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQBL-3/8-3/16-U
Festo part number567763
SizeStandard
Nominal width2.997 mm
Seal type on screw-in studCoating
Mounting positionAny
DesignL-shape
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight18.711 g
Mounting typeExternal hex 11/16
Pneumatic connection 1Male thread 3/8 NPT
Pneumatic connection 2For tubing OD 3/16"
Release ring colourGrey
Material noteRoHS compliant
Housing materialPBT
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQBL-3/8-3/16-U
EAN4052568369835
Zolltarifnummer90330090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformL-Form
ThreadNPT 3/8
Size BGStandard
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
