Push-in fitting in nickel-plated brass with female thread 1/4 NPT for tubing O.D. 1/2" QBF-1/4-1/2-U - Festo 564647

Festo ✓ Original product Brand new

The push-in fitting QBF-1/4-1/2-U combines female thread 1/4 NPT with a connection for tubing O.D. 1/2". The housing is made of nickel-plated brass, the nominal width is 10.008 mm and the permitted operating pressure -0.95 to 10 bar (vacuum included). Permitted ambient temperature: 0 to 60 °C.

Net
€3.98
excl. VAT
Item FES-564647
Manufacturer no. QBF-1/4-1/2-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in fitting QBF-1/4-1/2-U combines female thread 1/4 NPT with a connection for tubing O. D. 1/2". Nominal width 10.008 mm, operating pressure -0.95 to 10 bar.

Benefits

  • Female thread 1/4 NPT, sealed by coating
  • Connection for tubing O. D. 1/2"
  • Nominal width 10.008 mm
  • Operating pressure -0.95 to 10 bar, vacuum included
  • Housing in nickel-plated brass, corrosion resistance class 1
  • Tubing released by the push-pull principle via the release ring

Applications

The QBF-1/4-1/2-U suits systems with inch tubing (O. D. 1/2") and connects via female thread 1/4 NPT to valves, cylinders or service units.

Technical data

FeatureValue
TypeQBF-1/4-1/2-U
Festo part number564647
Sizestandard
Nominal width10.008 mm
Seal type on screw-in studcoating
Mounting positionany
Designstraight
Constructionpush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight53.1 g
Mounting typeexternal hex 7/8
Pneumatic connection 1female thread 1/4 NPT
Pneumatic connection 2for tubing O. D. 1/2"
Release ring colourgrey
Material noteRoHS compliant
Housing materialnickel-plated brass
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialhigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQBF-1/4-1/2-U
EAN4052568365332
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNickel-plated brass
ThreadNPT 1/4
Seal materialNBR, PTFE
MediumCompressed air
Thread typeInternal thread
Betriebsdruck max [bar]10
Pneumatic connectionNPT 1/4
Temperaturbereich0-60 °C
Temperature (max.)60
