Straight push-in connector for tubing OD 3/16", PBT QB-3/16T-U - Festo 564755
The QB-3/16T-U push-in connector extends tubing lines with an OD of 3/16" or rejoins them after damage. The QB-3/16T-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The QB-3/16T-U push-in connector extends tubing lines with an OD of 3/16" or rejoins them after damage. The QB-3/16T-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.
Benefits
- From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
- Ambient temperature 0 to 60 °C
- Push-pull principle push the tube in, press the grey release ring to remove it
- Housing made of PBTcorrosion resistance class CRC 1
- Tubing seal made of NBR
- LABS (PWIS) conformity to VDMA24364 zone III
Applications
QB-3/16T-U is used to extend and repair tubing lines with an OD of 3/16". The QB-3/16T-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..
Technical data
| Feature | Value |
|---|---|
| Type | QB-3/16T-U |
| Festo part number | 564755 |
| Size | Standard |
| Nominal width | 3.505 mm |
| Mounting position | Any |
| Design | Straight |
| Construction | Push-pull principle |
| Operating pressure, full temperature range | -0.95 to 10 bar |
| Operating medium | compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Product weight | 3.402 g |
| Pneumatic connection 1 | For tubing OD 3/16" |
| Pneumatic connection 2 | For tubing OD 3/16" |
| Release ring colour | Grey |
| Material note | RoHS compliant |
| Housing material | PBT |
| Release ring material | POM |
| Tubing seal material | NBR |
| Tubing clamp segment material | High-alloy stainless steel |
| Weight | 0.006 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QB-3/16T-U |
| EAN | 4052568366414 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Bauform | gerade Form |
| Size BG | Standard |
| Seal material | NBR |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
