Straight push-in fitting 10-32 UNF-2A to tubing OD 1/4", PBT QB-10-32-UNF-1/4-I-U - Festo 572316

Festo ✓ Original product Brand new

QB-10-32-UNF-1/4-I-U is the straight transition from a 10-32 UNF-2A thread to tubing with an OD of 1/4". Operating limits: 0.95 to 10 bar and 0 to 60 °C. The tube is pushed in and released again via the release ring.

Net
€2.00
excl. VAT
Item FES-572316
Manufacturer no. QB-10-32-UNF-1/4-I-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

QB-10-32-UNF-1/4-I-U is the straight transition from a 10-32 UNF-2A thread to tubing with an OD of 1/4". Operating limits: 0.95 to 10 bar and 0 to 60 °C.

Benefits

  • Operating pressure 0.95 to 10 bar
  • Ambient temperature 0 to 60 °C
  • Push-pull principle push the tube in, press the grey release ring to remove it
  • Housing made of PBTcorrosion resistance class CRC 1
  • Tubing seal made of NBR
  • LABS (PWIS) conformity to VDMA24364 zone III

Applications

The QB-10-32-UNF-1/4-I-U connects tubing lines to valves, actuators and manifolds with a 10-32 UNF-2A thread. The QB-10-32-UNF-1/4-I-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQB-10-32-UNF-1/4-I-U
Festo part number572316
SizeStandard
Nominal width2.388 mm
Seal type on screw-in studSealing ring
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Max. tightening torque1.5 Nm
Product weight8.789 g
Mounting typeInternal hex 3/32
Pneumatic connection 1Male thread 10-32 UNF-2A
Pneumatic connection 2For tubing OD 1/4"
Release ring colourGrey
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQB-10-32-UNF-1/4-I-U
EAN4052568374853
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
Bauformgerade Form
ThreadUNF 10-32
Size BGStandard
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
