Push-in fitting QB-1/8-1/4-U-M - Festo 533216
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Size | Standard |
|---|---|
| Nominal size | 5.004 mm |
| Type of seal on screwed plug | Coating |
| Design | Straight design |
| Size of pack | 10 |
| Operating pressure complete temperature range | 0.95 ... 10 bar |
| Maritime classification | See certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 ... 60 °C |
| Product weight | 8.789 g |
| Type of mounting | External hex SW13, Internal hexagon A/F 5 |
| Pneumatic connection, port 1 | Male thread R1/8 |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/4" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material thread seal | NBR |
| Material release ring | POM |
| Material tubing clamp component | High-alloy stainless steel |
| Weight | 0.01 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QB-1/8-1/4-U-M |
| EAN | 4052568340414 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
