Push-in fitting in nickel-plated brass with male thread 1/4 NPT for tubing O.D. 5/16" QB-1/4-5/16-U - Festo 533277

Festo ✓ Original product Brand new

The push-in fitting QB-1/4-5/16-U combines male thread 1/4 NPT with a connection for tubing O.D. 5/16". Operating pressure -0.95 to 10 bar, vacuum included, nominal width 6.401 mm, housing in nickel-plated brass. Permitted ambient temperature: 0 to 60 °C. CRC 1, low corrosion stress. RoHS compliant.

Net
€1.92
excl. VAT
Item FES-533277
Manufacturer no. QB-1/4-5/16-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in fitting QB-1/4-5/16-U combines male thread 1/4 NPT with a connection for tubing O. D. 5/16". The nominal width is 6.401 mm and the operating pressure -0.95 to 10 bar.

Benefits

  • Male thread 1/4 NPT with sealing coating
  • Connection for tubing O. D. 5/16"
  • Nominal width 6.401 mm
  • Operating pressure -0.95 to 10 bar, vacuum included
  • Housing in nickel-plated brass, corrosion resistance class 1
  • Tubing released by the push-pull principle via the release ring

Applications

The QB-1/4-5/16-U is suitable for working and control lines with O. D. 5/16", connected via male thread 1/4 NPT.

Technical data

FeatureValue
TypeQB-1/4-5/16-U
Festo part number533277
Sizestandard
Nominal width6.401 mm
Seal type on screw-in studcoating
Mounting positionany
Designstraight
Constructionpush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight14.714 g
Mounting typeexternal hex 9/16, internal hex 1/4
Pneumatic connection 1male thread 1/4 NPT
Pneumatic connection 2for tubing O. D. 5/16"
Release ring colourgrey
Material noteRoHS compliant
Housing materialnickel-plated brass
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialhigh-alloy stainless steel
Weight0.015 kg
ManufacturerFesto
Hersteller-NrQB-1/4-5/16-U
EAN4052568341022
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNickel-plated brass
ThreadNPT 1/4
Seal materialNBR, PTFE
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Pneumatic connectionNPT 1/4
Temperaturbereich0-60 °C
Temperature (max.)60
