Straight push-in fitting 1/2 NPT to tubing OD 5/16", nickel-plated brass QB-1/2-5/16-U - Festo 567770
QB-1/2-5/16-U is the straight transition from a 1/2 NPT thread to tubing with an OD of 5/16". Operating pressure -0.95 to 10 bar, ambient 0 to 60 °C. The tube is pushed in and released again via the release ring.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
QB-1/2-5/16-U is the straight transition from a 1/2 NPT thread to tubing with an OD of 5/16". Operating pressure -0.95 to 10 bar, ambient 0 to 60 °C.
Benefits
- From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
- Push-pull principle push the tube in, press the grey release ring to remove it
- Housing made of nickel-plated brasscorrosion resistance class CRC 1
- Tubing seal made of NBR
- Coated screw-in stud made of PTFE
- LABS (PWIS) conformity to VDMA24364 zone III
Applications
Typical locations for the QB-1/2-5/16-U are valves, cylinders and service units with a 1/2 NPT port. Approved medium for the QB-1/2-5/16-U: compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..
Technical data
| Feature | Value |
|---|---|
| Type | QB-1/2-5/16-U |
| Festo part number | 567770 |
| Size | Standard |
| Nominal width | 6.401 mm |
| Seal type on screw-in stud | Coating |
| Mounting position | Any |
| Design | Straight |
| Construction | Push-pull principle |
| Operating pressure, full temperature range | -0.95 to 10 bar |
| Operating medium | compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Product weight | 59.705 g |
| Mounting type | External hex 7/8, internal hex 1/4 |
| Pneumatic connection 1 | Male thread 1/2 NPT |
| Pneumatic connection 2 | For tubing OD 5/16" |
| Release ring colour | Grey |
| Material note | RoHS compliant |
| Housing material | Nickel-plated brass |
| Thread seal material | PTFE |
| Release ring material | POM |
| Tubing seal material | NBR |
| Tubing clamp segment material | High-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | QB-1/2-5/16-U |
| EAN | 4052568369903 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Bauform | gerade Form |
| Thread | NPT 1/2 |
| Size BG | Standard |
| Seal material | NBR |
| Medium | Compressed air |
| Thread type | External thread |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
