Straight push-in fitting 1/2 NPT to tubing OD 1/2", PBT QB-1/2-1/2-I-U - Festo 572326

Festo ✓ Original product Brand new

With the QB-1/2-1/2-I-U push-in fitting, tubing with an OD of 1/2" is connected to a 1/2 NPT thread without tools. The QB-1/2-1/2-I-U is specified for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature. The tube is pushed in and released again via the release ring.

Net
€4.34
excl. VAT
Item FES-572326
Manufacturer no. QB-1/2-1/2-I-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the QB-1/2-1/2-I-U push-in fitting, tubing with an OD of 1/2" is connected to a 1/2 NPT thread without tools. The QB-1/2-1/2-I-U is specified for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Housing made of PBTcorrosion resistance class CRC 1
  • Tubing seal made of NBR
  • Coated screw-in stud made of PTFE
  • LABS (PWIS) conformity to VDMA24364 zone III
  • Nominal width 9.601 mm

Applications

Typical locations for the QB-1/2-1/2-I-U are valves, cylinders and service units with a 1/2 NPT port. The QB-1/2-1/2-I-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQB-1/2-1/2-I-U
Festo part number572326
SizeStandard
Nominal width9.601 mm
Seal type on screw-in studCoating
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight43.092 g
Mounting typeInternal hex 3/8
Pneumatic connection 1Male thread 1/2 NPT
Pneumatic connection 2For tubing OD 1/2"
Release ring colourGrey
Material noteRoHS compliant
Housing materialPBT
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQB-1/2-1/2-I-U
EAN4052568374952
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
Bauformgerade Form
ThreadNPT 1/2
Size BGStandard
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
