Spiral plastic tubing PU 8 x 5.7 mm working length 2 m blue PUN-8X1,25-S-2-BL - Festo 197594
The spiral tubing PUN-8X1,25-S-2-BL extends to a working length of 2 m and retracts to 0.424 m afterwards. Operating pressure -0.95 to 10 bar and ambient -35 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The spiral plastic tubing PUN-8X1,25-S-2-BL supplies moving consumers over a working length of 2 m and returns to its starting position by itself after extension.
Benefits
- Operating pressure -0.95 to 10 bar (temperature-dependent)
- Working length 2 m with 0.424 m block length and 27 turns
- Shore hardness D 52 ± 3
- Ambient temperature -35 to 60 °C
- Approval TÜV
Applications
Operating medium compressed air to ISO 8573-1:2010 [7:-:-]. Typical on hand tools and blow guns.
Technical data
| Feature | Value |
|---|---|
| Type | PUN-8X1,25-S-2-BL |
| Festo part number | 197594 |
| Working length | 2 m |
| Outside diameter | 8 mm |
| Block length | 0.424 m |
| Inside diameter | 5.7 mm |
| Winding diameter | 60 mm |
| Number of turns | 27 |
| Temperature-dependent operating pressure | -0.95 to 10 bar |
| Approval | TÜV |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -35 to 60 °C |
| Colour | Blue |
| Shore hardness | D 52 ± 3 |
| Material tubing | TPE-U(PU) |
| Weight (price list) | 0.17 kg |
| Weight | 0.17 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PUN-8X1,25-S-2-BL |
| EAN | 4052568082451 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | blau |
| Material | Polyurethan |
| Medium | Compressed air |
| Schlauchdurchmesser (außen) [mm] | 8 |
| Schlauchdurchmesser (außen x innen) [mm] | 8 x 5,7 |
| Schlauchdurchmesser (innen) [mm] | 5,7 |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | -35-60 °C |
