Plastic tubing PU 11.6 x 9 mm black PU-9-SW - Festo 12134
Polyurethane tubing 11.6 x 9 mm for push-in fittings with 11.6 mm outside diameter. Operating pressure 0 to 10 bar and ambient -35 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The plastic tubing PU-9-SW carries compressed air between valves, cylinders and service units. Connection: for barbed fitting inside diameter of 9 mm with union nut.
Benefits
- Operating pressure 0 to 10 bar
- Shore hardness A 91 ± 3
- Ambient temperature -35 to 60 °C
Applications
Permitted media: compressed air to ISO 8573-1:2010 [7:-:-].
Technical data
| Feature | Value |
|---|---|
| Type | PU-9-SW |
| Festo part number | 12134 |
| Outside diameter | 11.6 mm |
| Flow-relevant bending radius | 76 mm |
| Inside diameter | 9 mm |
| Operating pressure complete temperature range | 0 to 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -35 to 60 °C |
| Product weight according to length | 0.056 kg/m |
| Pneumatic connection | For barbed fitting inside diameter of 9 mm with union nut |
| Colour | Black |
| Shore hardness | A 91 ± 3 |
| Note on materials | RoHS compliant |
| Material tubing | TPE-U(PU) |
| Weight | 0.055 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PU-9-SW |
| EAN | 4052568021412 |
| Zolltarifnummer | 39173900 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | schwarz |
| Material | Polyurethan |
| Medium | Compressed air |
| Schlauchdurchmesser (außen) [mm] | 11,6 |
| Schlauchdurchmesser (außen x innen) [mm] | 11,6 x 9 |
| Schlauchdurchmesser (innen) [mm] | 9 |
| Series | PU |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | -35-60 °C |
