Press fitting, pipe 22 mm, stainless steel 1.4404, seal FKM, for compressed air

This press fitting joins a pipe of 22 mm outside diameter and the continuing line in one part. The material is stainless steel 1.4404, the size is fixed at pipe diameter 22 mm.

Benefits

• The installation dimensions a of 63 mm and z of 35 mm are stated
• The press joint is made in a single operation without an open flame
• The size 22 is clearly assigned and stays available for reordering
• With pipe diameter 22 mm the size is fixed, so no reworking of the line is required

Applications

Refurbishment of existing pipe networks, compressed air networks in workshop and hall, water and cooling circuits, cooling and heating water lines.

Standards and conformity

Pressing is done with jaws of the SA, M and V press profiles.
