45 degree press fitting bend, tube 18 mm, nipple 18 mm, stainless steel

The material is stainless steel, the size is fixed at tube diameter 18 mm. The 45 degree press fitting bend connects a tube of 18 mm outside diameter and a nipple of 18 mm diameter in doing so. The 45 degree design continues the line at an angle and avoids tight bends.

Benefits

• The size 18 is clearly assigned and stays available for reordering
• With tube diameter 18 mm the size is fixed, so no reworking of the line is required
• The change of direction by 45 degrees saves installation length ahead of the port
• The installation dimensions a of 39 mm and z of 13 mm are stated
• The press joint is made in a single operation without an open flame

Technical data

Applications

Refurbishment of existing pipe networks, compressed air networks in workshop and hall, water and cooling circuits, cooling and heating water lines.

Standards and conformity

Pressing is done with jaws of the SA, M and V press profiles.
