ISOLine profile cylinder, double acting, 125 mm bore, 250 mm stroke - Norgren PRA/802125/W2/EX/250

Images are examples, some edited with AI. The technical data are authoritative. AI notice

ISOLine profile cylinder, double acting, 125 mm bore, 250 mm stroke - Norgren PRA/802125/W2/EX/250

Norgren ✓ Original product Brand new

Fits existing fixtures because the dimensions follow ISO 15552. Norgren PRA/802125/W2/EX/250 has 125 mm piston diameter, 250 mm stroke and port G1/2.

Net
€694.34
excl. VAT
Item NRG-PRA/802125/W2/EX/250
Manufacturer no. PRA/802125/W2/EX/250
Save Compare
Question about this item
Datasheet (PDF)
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The profile cylinder Norgren PRA/802125/W2/EX/250 is built to ISO 15552 and works with 125 mm piston diameter over 250 mm of stroke.

Benefits

  • Theoretical force 7363 N at 6 bar
  • Port G1/2 on both sides
  • Operating pressure 1 to 10 bar
  • Temperature range -20 to 60 °C
  • Barrel made of anodised aluminium
  • Piston rod made of stainless steel (martensitic) with male thread

Applications

The cylinder is used in fixtures, feeding technology and special machines that need 250 mm of stroke and a force of 7363 N.

Standards and conformity

The dimensions conform to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The piston seal is made of Polyurethane (PU). The permissible temperature range is -20 to 60 °C.

Technical data

PropertyValue
Manufacturer part numberNorgren PRA/802125/W2/EX/250
SeriesPRA/802000/M/EX
Product lineISOLine
StandardISO 15552
Operating modeDouble acting
Port sizeG1/2
Piston diameter125 mm
Stroke250 mm
Theoretical force at 6 bar7363 N
Operating pressure1 to 10 bar
MediumCompressed air
Temperature range-20 to 60 °C
CushioningAdaptive cushioning system ACS
Piston versionMagnetic
Cylinder barrelAnodised aluminium
Piston rod materialStainless steel (martensitic)
Piston rod threadMale thread
Piston sealPolyurethane (PU)
Piston rod sealPolyurethane (PU)
ManufacturerNorgren
Hersteller-NrPRA/802125/W2/EX/250
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
NormISO 15552, VDMA 24562
