Pneufit C push-in side swivel tee adaptor, 1/4 NPT, tube 5/16 in - Norgren C24680528
The Norgren C24680528 Pneufit C push-in side swivel tee adaptor connects 5/16 in OD tubes to a 1/4 NPT port and can be turned to the required direction after installation. Key data of the C24680528: tube outside diameter 5/16 in, external thread 1/4 NPT, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren C24680528 Pneufit C push-in side swivel tee adaptor connects 5/16 in OD tubes to a 1/4 NPT port and can be turned to the required direction after installation. Key data of the C24680528: tube outside diameter 5/16 in, external thread 1/4 NPT, operating pressure -0.9 to 10 bar and temperature range -20 to 60 °C.
Benefits
- Releasable stainless steel grab ring: the C24680528 grips nylon or polyurethane tube (85 or 95 durometer) with 5/16 in OD.
- PBT body with nickel plated brass components: the C24680528 resists corrosion and contamination.
- 1/4 NPT taper thread with pre-applied sealant: the C24680528 seals without additional tape.
- Silicone-free U-packing: the C24680528 seals immediately on insertion.
- Operating pressure -0.9 to 10 bar: the C24680528 works with positive pressure and vacuum, at -20 to 60 °C.
Applications
Typical locations for the C24680528 are cylinders, valves and air preparation units in general industrial automation.
Compliance
According to Norgren, the C24680528 is RoHS compliant.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | C24680528 |
| Product type | Push-in side swivel tee adaptor |
| Series | Pneufit C |
| Shape | Tee |
| Tube outside diameter | 5/16 in |
| External thread | 1/4 NPT |
| Operating pressure | -0.9 to 10 bar |
| Medium | compressed air |
| Temperature range | -20 to 60 °C |
| Body material | Polybutylene terephthalate (PBT) |
| Seal material | Nitrile rubber (NBR) |
| External hexagon | 9/16" |
| Application area | general industrial automation |
| RoHS | compliant |
| Hersteller-Nr | C24680528 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Thread | NPT 1/4 |
| Design | T-shape |
| Thread type | External thread |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/4 |
| Temperaturbereich | -20-60 °C |
| Temperature (max.) | 60 |
