Plastic tubing PE 10 x 7 mm red PLN-10X1,5-RT - Festo 558220
Pneumatic tubing PLN-10X1,5-RT in polyethylene, OD 10 mm, ID 7 mm. Operating pressure -0.95 to 14 bar, bending radius from 22 mm and ambient -30 to 80 °C. Suitable for water as well as compressed air.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The PLN-10X1,5-RT is a plastic tubing in polyethylene with 10 mm outside diameter.
Benefits
- Operating pressure -0.95 to 14 bar (temperature-dependent)
- Minimum bending radius 22 mm, flow-relevant 57 mm
- Ambient temperature -30 to 80 °C
- Approval TÜV
Applications
Medium: compressed air to ISO 8573-1:2010 [7:-:-], water.
Technical data
| Feature | Value |
|---|---|
| Type | PLN-10X1,5-RT |
| Festo part number | 558220 |
| Outside diameter | 10 mm |
| Flow-relevant bending radius | 57 mm |
| Inside diameter | 7 mm |
| Minimum bending radius | 22 mm |
| Temperature-dependent operating pressure | -0.95 to 14 bar |
| Approval | TÜV |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free) |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -30 to 80 °C |
| Product weight according to length | 0.0375 kg/m |
| Colour | Red |
| Note on materials | RoHS compliant |
| Weight | 0.046 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PLN-10X1,5-RT |
| EAN | 4052568053932 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | rot |
| Material | Polyethylene |
| Medium | Compressed air, water |
| Schlauchdurchmesser (außen) [mm] | 10 |
| Schlauchdurchmesser (außen x innen) [mm] | 10 x 7 |
| Schlauchdurchmesser (innen) [mm] | 7 |
| min. Biegeradius [mm] | 22 |
| Betriebsdruck max [bar] | 14 |
| Temperaturbereich | -30-80 °C |
