Micro filter for high-purity compressed air, size 186, 0.01 µm, up to 50 bar PFML-186-HP3-AST - Festo 1364705
The PFML-186-HP3-AST micro filter removes the finest particles and oil aerosols from the compressed air. Key data: size 186, operating pressure 0 to 50 bar, grade of filtration 0.01 µm and housing made of wrought aluminium alloy.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The PFML-186-HP3-AST micro filter removes the finest particles and oil aerosols from the compressed air. The key values: size 186 and operating pressure 0 to 50 bar.
Benefits
- Rated for an operating pressure of 0 to 50 bar
- Grade of filtration 0.01 µm
- Air purity at the outlet: compressed air to ISO 8573-1:2010 [1:4:2]
- Volume 3
- Filter efficiency 99.99998 %
- Ambient temperature 5 to 60 °C
Application
It is used upstream of sensitive consumers and activated carbon filters. The PFML-186-HP3-AST works with inert gases.
Technical data
| Type | PFML-186-HP3-AST |
|---|---|
| Festo part number | 1364705 |
| Series | L |
| Size | 186 |
| Design | fibre filter |
| Grade of filtration | 0.01 µm |
| Condensate drain | manual |
| Operating pressure | 0 to 50 bar |
| Operating medium | inert gases |
| Note on operating and pilot medium | lubricated operation not possible |
| Air purity class at outlet | compressed air to ISO 8573-1:2010 [1:4:2] |
| Max. standard flow rate for air purity class | 10220 l/min |
| Min. standard flow rate for air purity class | 3406 l/min |
| Filter efficiency | 99.99998 % |
| Max. condensate volume | 200 ml |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| PWIS conformity | VDMA24364 zone III |
| Food suitability | see supplementary material information |
| Medium temperature | 5 to 60 °C |
| Ambient temperature | 5 to 60 °C |
| Storage temperature | -10 to 60 °C |
| CE marking (see declaration of conformity) | in accordance with EU Pressure Equipment Directive |
| UKCA marking (see declaration of conformity) | to UK Pressure Equipment Regulations |
| Mounting type | inline installation |
| Mounting position | vertical ± 5° |
| Housing material | wrought aluminium alloy |
| Filter material | borosilicate fibre |
| Bowl material | high-alloy stainless steel |
| Seal material | NBR |
| Note on materials | RoHS-compliant |
| Product weight | 17900 g |
| Volume | 3 |
| Weight | 18 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PFML-186-HP3-AST |
| EAN | 4052568263003 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Filter grade [µm] | 0,01 |
| Betriebsdruck max [bar] | 50 |
| Temperaturbereich | 5-60 °C |
| Temperature (max.) | 60 |
