Plastic tubing PEN-8X1,25-BL-400 - Festo 551446
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Outside diameter | 8 mm |
|---|---|
| Flow-relevant bending radius | 35 mm |
| Inside diameter | 5.7 mm |
| Min. bending radius | 22.5 mm |
| Tubing characteristics | Suitable for energy chains |
| Temperature-dependent operating pressure | -0.95 ... 10 bar |
| Note on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C |
| Approval | German Technical Control Board (TÜV) |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free) |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Ambient temperature | -30 ... 60 °C |
| Product weight according to length | 0.02327 kg/m |
| Pneumatic connection | For push-in connector O.D. 8 mm, For push-in connector outside diameter of 5/16", For barbed fitting inside diameter of 6 mm with union nut, For barbed fitting inside diameter of 6 mm |
| Colour | Blue |
| Shore hardness | D 52 +/-3 |
| Note on materials | RoHS compliant |
| Material tubing | Packaging unit |
| Weight | 0.036 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PEN-8X1,25-BL-400 |
| EAN | 4052568052324 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
