Filter regulator ATEX 0.5 to 8 bar 40 µm without pressure gauge PCRI-100-F90-12-E-T3 - Festo 8141657
Directly actuated diaphragm regulator with an integrated 40 µm filter: the PCRI-100-F90-12-E-T3 regulates from 0.5 to 8 bar at 1,400 l/min standard nominal flow and compensates supply pressure fluctuations. The smooth-anodised wrought aluminium housing reaches CRC 3 and is approved for ATEX zones 1, 2, 21 and 22.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo filter regulator PCRI-100-F90-12-E-T3: pressure regulation range 0.5 to 8 bar, grade of filtration 40 µm, standard nominal flow 1,400 l/min.
Benefits
- 40 µm grade of filtration, air purity class at output [7:7:-] to ISO 8573-1:2010
- Pressure regulation range 0.5 to 8 bar, max. pressure hysteresis 0.25 bar, input pressure up to 9 bar
- Standard nominal flow rate 1,400 l/min to DIN 1343
- Gauge port G1/4 prepared, display selectable as required
- Rotary knob with detent, set pressure stays fixed
- Corrosion resistance class CRC 3
Applications
The PCRI-100-F90-12-E-T3 is approved for Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX). It is connected via a sub-base, mounting position is any, medium temperature -40 to 80 °C. Lubricated air is not permitted for the PCRI-100-F90-12-E-T3.
Technical data
| Feature | Value |
|---|---|
| Type | PCRI-100-F90-12-E-T3 |
| Festo part number | 8141657 |
| Actuator lock | rotary knob with detent |
| Mounting position | any |
| Grade of filtration | 40 µm |
| Condensate drain | none |
| Design | directly actuated diaphragm regulator |
| Regulator function | output pressure constant, with supply pressure compensation, with secondary exhaust |
| Pressure gauge | prepared for G1/4 |
| Operating pressure | 1 to 9 bar |
| Pressure regulation range | 0.5 to 8 bar |
| Max. pressure hysteresis | 0.25 bar |
| Standard nominal flow rate | 1400 l/min (to DIN 1343) |
| Explosion protection | Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX) |
| Operating medium | inert gases |
| Note on operating and pilot medium | lubricated operation not possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Air purity class at output | compressed air to ISO 8573-1:2010 [7:7:-], inert gases |
| Medium temperature | -40 to 80 °C |
| Ambient temperature | -40 to 80 °C |
| Product weight | 1950 g |
| Pneumatic connection | sub-base design, Airing |
| Note on materials | RoHS-compliant |
| Cover material | wrought aluminium alloy, smooth-anodised (20 µm) |
| Seal material | EPDM, NBR |
| Rotary knob material | POM |
| Spring material | spring steel |
| Filter material | PE |
| Housing material | wrought aluminium alloy, smooth-anodised (20 µm) |
| Screw material | high-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | PCRI-100-F90-12-E-T3 |
| EAN | 4052568580285 |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Control range max. [bar] | 8 |
| Flow rate [l/min] | 1400 |
| Filter grade [µm] | 40 |
| Druckregelbereich [bar] | 0,5-8 |
| Medientemperatur [°C] | -40 bis 80 |
| Betriebsdruck max [bar] | 9 |
| Temperaturbereich | -40-80 °C |
| Temperature (max.) | 80 |
