Filter regulator ATEX 0.5 to 8 bar 5 µm without pressure gauge PCRI-100-F90-12-C-T3 - Festo 8141656

Festo ✓ Original product Brand new

Directly actuated diaphragm regulator with an integrated 5 µm filter: the PCRI-100-F90-12-C-T3 regulates from 0.5 to 8 bar at 1,400 l/min standard nominal flow and compensates supply pressure fluctuations. The smooth-anodised wrought aluminium housing reaches CRC 3 and is approved for ATEX zones 1, 2, 21 and 22.

Net
€517.43
excl. VAT
Item FES-8141656
Manufacturer no. PCRI-100-F90-12-C-T3
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Festo filter regulator PCRI-100-F90-12-C-T3: pressure regulation range 0.5 to 8 bar, grade of filtration 5 µm, standard nominal flow 1,400 l/min.

Benefits

  • 5 µm grade of filtration, air purity class at output [6:7:-] to ISO 8573-1:2010
  • Standard nominal flow rate 1,400 l/min to DIN 1343
  • Gauge port G1/4 prepared, display selectable as required
  • Rotary knob with detent, set pressure stays fixed
  • Corrosion resistance class CRC 3
  • Pressure regulation range 0.5 to 8 bar, max. pressure hysteresis 0.25 bar, input pressure up to 9 bar

Applications

The PCRI-100-F90-12-C-T3 is approved for Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX). It is connected via a sub-base, mounting position is any, medium temperature -40 to 80 °C. Lubricated air is not permitted for the PCRI-100-F90-12-C-T3.

Technical data

FeatureValue
TypePCRI-100-F90-12-C-T3
Festo part number8141656
Actuator lockrotary knob with detent
Mounting positionany
Grade of filtration5 µm
Condensate drainnone
Designdirectly actuated diaphragm regulator
Regulator functionoutput pressure constant, with supply pressure compensation, with secondary exhaust
Pressure gaugeprepared for G1/4
Operating pressure1 to 9 bar
Pressure regulation range0.5 to 8 bar
Max. pressure hysteresis0.25 bar
Standard nominal flow rate1400 l/min (to DIN 1343)
Explosion protectionZone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX)
Operating mediuminert gases
Note on operating and pilot mediumlubricated operation not possible
Corrosion resistance class CRC3 - high corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Air purity class at outputcompressed air to ISO 8573-1:2010 [6:7:-], inert gases
Medium temperature-40 to 80 °C
Ambient temperature-40 to 80 °C
Product weight1950 g
Pneumatic connectionsub-base design, Airing
Note on materialsRoHS-compliant
Cover materialwrought aluminium alloy, smooth-anodised (20 µm)
Seal materialEPDM, NBR
Rotary knob materialPOM
Spring materialspring steel
Filter materialPE
Housing materialwrought aluminium alloy, smooth-anodised (20 µm)
Screw materialhigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrPCRI-100-F90-12-C-T3
EAN4052568580278
Zolltarifnummer84811005
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Control range max. [bar]8
Flow rate [l/min]1400
Filter grade [µm]5
Druckregelbereich [bar]0,5-8
Medientemperatur [°C]-40 bis 80
Betriebsdruck max [bar]9
Temperaturbereich-40-80 °C
Temperature (max.)80
