Heavy-duty tubing OD 8 mm, ID 5 mm, made of TPE-A, silver PAN-R-8X1,5-SI - Festo 541676
The PAN-R-8X1,5-SI heavy-duty tubing is a Festo compressed-air line for push-in fittings and barbed connectors. Suitable for push-in connector OD 8 mm. With 8 mm outside and 5 mm inside diameter.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The PAN-R-8X1,5-SI heavy-duty tubing is a Festo compressed-air line for push-in fittings and barbed connectors. Pressure range -0.95 to 35 bar, depending on temperature.
Benefits
- OD 8 mm, ID 5 mm
- Temperature-dependent operating pressure -0.95 to 35 bar, vacuum-capable
- Tight routing with a minimum bending radius of 20 mm
- Suitable for energy chains and moving lines
- TÜV approval
- Ambient temperature -30 to 80 °C
Applications
For tubing valve terminals, cylinders and service units in machine and plant building.
Technical data
| Feature | Value |
|---|---|
| Type | PAN-R-8X1,5-SI |
| Festo part number | 541676 |
| Product type | Heavy-duty tubing |
| Outside diameter | 8 mm |
| Flow-relevant bending radius | 29 mm |
| Inside diameter | 5 mm |
| Minimum bending radius | 20 mm |
| Tubing characteristics | suitable for energy chains |
| Temperature-dependent operating pressure | -0.95 to 35 bar |
| Approval | TÜV |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| PWIS (LABS) conformity | VDMA24364-B2-L |
| Ambient temperature | -30 to 80 °C |
| Weight per metre | 0.0316 kg/m |
| Pneumatic connection | For push-in connector OD 8 mm |
| Colour | silver |
| Shore hardness | D 62 +/-3 |
| Material note | RoHS compliant |
| Tubing material | TPE-A |
| Weight | 0.035 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PAN-R-8X1,5-SI |
| EAN | 4052568050603 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | silber |
| For hose OD [mm] | 8 |
| For hose ID [mm] | 5 |
| Medium | Compressed air |
| Schlauchdurchmesser (außen) [mm] | 8 |
| Schlauchdurchmesser (innen) [mm] | 5 |
| min. Biegeradius [mm] | 20 |
| Series | PAN |
| Betriebsdruck max [bar] | 35 |
| Temperaturbereich | -30-80 °C |
| Temperature (max.) | 80 |
