Plastic tubing OD 8 mm, ID 5.9 mm, made of TPE-A, natural PAN-8X1,25-NT - Festo 546286

Festo ✓ Original product Brand new

The PAN-8X1,25-NT plastic tubing routes compressed air between valve, distributor and actuator. Suitable for push-in connector OD 8 mm or barbed fitting ID 6 mm. With 8 mm outside and 5.9 mm inside diameter.

Net
€2.90
excl. VAT
Item FES-546286
Manufacturer no. PAN-8X1,25-NT
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The PAN-8X1,25-NT plastic tubing routes compressed air between valve, distributor and actuator. Usable from vacuum (-0.95 bar) up to 15 bar, depending on temperature.

Benefits

  • OD 8 mm, ID 5.9 mm
  • Temperature-dependent operating pressure -0.95 to 15 bar, vacuum-capable
  • Tight routing with a minimum bending radius of 22 mm
  • Suitable for energy chains and moving lines
  • TÜV approval
  • Ambient temperature -30 to 80 °C

Applications

For pneumatic control and working lines in automation.

Technical data

FeatureValue
TypePAN-8X1,25-NT
Festo part number546286
Product typePlastic tubing
Outside diameter8 mm
Flow-relevant bending radius43 mm
Inside diameter5.9 mm
Minimum bending radius22 mm
Tubing characteristicssuitable for energy chains
Temperature-dependent operating pressure-0.95 to 15 bar
ApprovalTÜV
Marine classificationsee certificate
Certificate issuing authority61630/B0 BV, B 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
PWIS (LABS) conformityVDMA24364-B2-L
Ambient temperature-30 to 80 °C
Weight per metre0.024 kg/m
Pneumatic connectionFor push-in connector OD 8 mm, for barbed fitting ID 6 mm with or without union nut
Colournatural
Shore hardnessD 55 +/-3
Material noteRoHS compliant
Tubing materialTPE-A
Weight0.028 kg
ManufacturerFesto
Hersteller-NrPAN-8X1,25-NT
EAN4052568051297
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbenatur
For hose OD [mm]8
MediumCompressed air
Schlauchdurchmesser (außen) [mm]8
Schlauchdurchmesser (innen) [mm]5,9
min. Biegeradius [mm]22
SeriesPAN
Betriebsdruck max [bar]15
Temperaturbereich-30-80 °C
Temperature (max.)80
