Plastic tubing OD 12 mm, ID 8.4 mm, made of TPE-A, natural PAN-12X1,75-NT - Festo 546288

Festo ✓ Original product Brand new

The PAN-12X1,75-NT plastic tubing routes compressed air between valve, distributor and actuator. Suitable for push-in connector OD 12 mm. With 12 mm outside and 8.4 mm inside diameter.

Net
€5.85
excl. VAT
Item FES-546288
Manufacturer no. PAN-12X1,75-NT
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The PAN-12X1,75-NT plastic tubing routes compressed air between valve, distributor and actuator. Pressure range -0.95 to 17 bar, depending on temperature.

Why the PAN-12X1,75-NT

  • OD 12 mm, ID 8.4 mm
  • Temperature-dependent operating pressure -0.95 to 17 bar, vacuum-capable
  • Tight routing with a minimum bending radius of 29 mm
  • Suitable for energy chains and moving lines
  • TÜV approval
  • Ambient temperature -30 to 80 °C

Applications

For tubing valve terminals, cylinders and service units in machine and plant building.

Technical data

FeatureValue
TypePAN-12X1,75-NT
Festo part number546288
Product typePlastic tubing
Outside diameter12 mm
Flow-relevant bending radius64 mm
Inside diameter8.4 mm
Minimum bending radius29 mm
Tubing characteristicssuitable for energy chains
Temperature-dependent operating pressure-0.95 to 17 bar
ApprovalTÜV
Marine classificationsee certificate
Certificate issuing authority61630/B0 BV, B 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
PWIS (LABS) conformityVDMA24364-B2-L
Ambient temperature-30 to 80 °C
Weight per metre0.06 kg/m
Pneumatic connectionFor push-in connector OD 12 mm
Colournatural
Shore hardnessD 55 +/-3
Material noteRoHS compliant
Tubing materialTPE-A
Weight0.07 kg
ManufacturerFesto
Hersteller-NrPAN-12X1,75-NT
EAN4052568051310
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbenatur
For hose OD [mm]12
MediumCompressed air
Schlauchdurchmesser (außen) [mm]12
Schlauchdurchmesser (innen) [mm]8,4
min. Biegeradius [mm]29
SeriesPAN
Betriebsdruck max [bar]17
Temperaturbereich-30-80 °C
Temperature (max.)80
