Plastic tubing OD 10 mm, ID 7 mm, made of TPE-A, natural PAN-10X1,5-NT - Festo 546287

Festo ✓ Original product Brand new

The PAN-10X1,5-NT plastic tubing is a Festo compressed-air line for push-in fittings and barbed connectors. Suitable for push-in connector OD 10 mm. Outside diameter 10 mm, inside diameter 7 mm.

Net
€4.17
excl. VAT
Item FES-546287
Manufacturer no. PAN-10X1,5-NT
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The PAN-10X1,5-NT plastic tubing is a Festo compressed-air line for push-in fittings and barbed connectors. Usable from vacuum (-0.95 bar) up to 17 bar, depending on temperature.

Benefits

  • OD 10 mm, ID 7 mm
  • Temperature-dependent operating pressure -0.95 to 17 bar, vacuum-capable
  • Tight routing with a minimum bending radius of 27 mm
  • Suitable for energy chains and moving lines
  • TÜV approval
  • Ambient temperature -30 to 80 °C

Applications

Typical for compressed-air lines on machines, in control cabinets and on moving axes.

Technical data

FeatureValue
TypePAN-10X1,5-NT
Festo part number546287
Product typePlastic tubing
Outside diameter10 mm
Flow-relevant bending radius58 mm
Inside diameter7 mm
Minimum bending radius27 mm
Tubing characteristicssuitable for energy chains
Temperature-dependent operating pressure-0.95 to 17 bar
ApprovalTÜV
Marine classificationsee certificate
Certificate issuing authority61630/B0 BV, B 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
PWIS (LABS) conformityVDMA24364-B2-L
Ambient temperature-30 to 80 °C
Weight per metre0.042 kg/m
Pneumatic connectionFor push-in connector OD 10 mm
Colournatural
Shore hardnessD 55 +/-3
Material noteRoHS compliant
Tubing materialTPE-A
Weight0.047 kg
ManufacturerFesto
Hersteller-NrPAN-10X1,5-NT
EAN4052568051303
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbenatur
For hose OD [mm]10
For hose ID [mm]7
MediumCompressed air
Schlauchdurchmesser (außen) [mm]10
Schlauchdurchmesser (innen) [mm]7
min. Biegeradius [mm]27
SeriesPAN
Betriebsdruck max [bar]17
Temperaturbereich-30-80 °C
Temperature (max.)80
