Vacuum generator with switch-on valve and vacuum switch Laval nozzle 0.45 mm vacuum 93 % OVEM-05-H-B-QO-CE-N-PI - Festo 604905
With a 0.45 mm Laval nozzle, the vacuum generator OVEM-05-H-B-QO-CE-N-PI reaches up to 93 % vacuum at a max. suction flow of 6 l/min. Integrated functions: vacuum switch and electric switch-on valve.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The vacuum generator OVEM-05-H-B-QO-CE-N-PI works with a 0.45 mm Laval nozzle. Ejector characteristic: high vacuum, Standard.
Benefits
- Vacuum up to 93 %
- Suction flow up to 6 l/min against atmosphere
- Electrics: connection M12x1, Plug
- Vacuum monitoring with integrated vacuum switch
Applications
For dense surfaces where high vacuum defines the holding force, for example sheet metal, glass or film on a smooth carrier.
Technical data
| Nominal size, Laval nozzle | 0.45 mm |
|---|---|
| Design | Modular |
| Ejector characteristic | High vacuum, Standard |
| Maximum vacuum | 93 % |
| Maximum suction flow rate against atmosphere | 6 l/min |
| Operating pressure | 2 to 8 bar |
| Valve function | Closed |
| Integrated function | Vacuum switch, Electric switch-on valve |
| Electrical connection | M12x1, Plug |
| Weight | 0.55 kg |
| Manufacturer | Festo |
| Hersteller-Nr | OVEM-05-H-B-QO-CE-N-PI |
| Zolltarifnummer | 84141089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | closed |
| Series | OVEM |
| Betriebsdruck max [bar] | 8 |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
