Olympian Plus soft start monitored dump valve, G3/8, 3-10 bar - Norgren P64S-3GC-N1N

Soft start dump valves build up pressure in a controlled way and vent the plant on shut-down. The Olympian Plus soft start monitored dump valve Norgren P64S-3GC-N1N has a body made of zinc alloy and is suitable for compressed air.

Benefits

• Downstream pressure rises in a controlled way on start up
• Monitored dump function
• Variable snap adjustment
• Port size G3/8
• Operating pressure 3 to 10 bar
• Flow 57 dm³/s

Applications

Typical installations are supply lines with safety requirements at start-up.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 5,000,000 cycles.
