Olympian Plus general purpose pressure regulator, without yoke, 0.4-8 bar - Norgren R68G-NNT-RLN

Name: Olympian Plus general purpose pressure regulator, without yoke, 0.4-8 bar - Norgren R68G-NNT-RLN
Brand: Norgren
SKU: NRG-R68G-NNT-RLN
Price: 207.69 EUR
Availability: InStock

Norgren ✓ Original product Brand new

Regulation stays even when demand changes. The Olympian Plus general purpose pressure regulator Norgren R68G-NNT-RLN accepts an inlet pressure up to 20 bar and is manufactured in Czechia.

Net

€207.69

excl. VAT

Item NRG-R68G-NNT-RLN

Manufacturer no. R68G-NNT-RLN

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Pressure regulators keep the working pressure constant even when the line pressure varies. The Olympian Plus general purpose pressure regulator Norgren R68G-NNT-RLN has a body made of aluminium alloy and is manufactured in Czechia.

Benefits

Diaphragm and balanced valve give good regulation characteristics
Non-rising adjusting knob with snap-action lock
Port size Without yoke
Outlet pressure adjustable from 0.4 to 8 bar
Flow 170 dm³/s
Temperature range -20 to 80 °C

Applications

The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.

Technical data

Property	Value
Manufacturer part number	Norgren R68G-NNT-RLN
Series	R68G
Product line	Olympian Plus
Regulator type	General purpose
Relieving function	Relieving
Adjustment	T-bar
Adjusting knob	Zinc plated steel
Port size	Without yoke
Maximum inlet pressure	20 bar
Adjustable outlet pressure	0.4 to 8 bar
Flow	170 dm³/s
Medium	Compressed air
Temperature range	-20 to 80 °C
Body material	Aluminium alloy
Spring bonnet	Aluminium alloy
Seal material	Nitrile rubber (NBR)
Height	234 mm
Width	91 mm
Length	111 mm
Weight	1.16 kg
Country of origin	Czechia
RoHS	Compliant
REACH	SVHC substance not present
WEEE	Non-WEEE
Manufacturer	Norgren
Hersteller-Nr	R68G-NNT-RLN
Zolltarifnummer	84811099
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
