Olympian Plus general purpose pressure regulator, G3/4, 0.7-17 bar, with gauge - Norgren R64G-6GT-RSG
Keeps the working pressure stable and thereby lowers air consumption. The Olympian Plus general purpose pressure regulator Norgren R64G-6GT-RSG covers the temperature range -20 to 80 °C and reaches a flow of 120 dm³/s.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure regulators keep the working pressure constant even when the line pressure varies. The Olympian Plus general purpose pressure regulator Norgren R64G-6GT-RSG reaches a flow of 120 dm³/s and covers the temperature range -20 to 80 °C.
Benefits
- Diaphragm and balanced valve give good regulation characteristics
- Non-rising adjusting knob with snap-action lock
- Port size G3/4
- Outlet pressure adjustable from 0.7 to 17 bar
- Flow 120 dm³/s
- Temperature range -20 to 80 °C
Applications
Typical installations are production lines, test benches and machines with several pressure levels.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren R64G-6GT-RSG |
| Series | R64G |
| Product line | Olympian Plus |
| Regulator type | General purpose |
| Relieving function | Relieving |
| Adjustment | T-bar |
| Adjusting knob | Zinc plated steel |
| Port size | G3/4 |
| Maximum inlet pressure | 17 bar |
| Adjustable outlet pressure | 0.7 to 17 bar |
| Flow | 120 dm³/s |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Body material | Zinc alloy |
| Spring bonnet | Aluminium alloy |
| Seal material | Nitrile rubber (NBR) |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | R64G-6GT-RSG |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day. Ask a question
