Olympian Plus general purpose pressure regulator, G3/4, 0.3-4 bar, without gauge - Norgren R64G-6GK-NFN
Regulation stays even when demand changes. The Olympian Plus general purpose pressure regulator Norgren R64G-6GK-NFN is suitable for compressed air and is designed for port G3/4.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure regulators keep the working pressure constant even when the line pressure varies. The Olympian Plus general purpose pressure regulator Norgren R64G-6GK-NFN accepts an inlet pressure up to 17 bar and seals with nitrile rubber (nbr).
Benefits
- Diaphragm and balanced valve give good regulation characteristics
- Non-rising adjusting knob with snap-action lock
- Port size G3/4
- Outlet pressure adjustable from 0.3 to 4 bar
- Flow 120 dm³/s
- Temperature range -20 to 80 °C
Applications
The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren R64G-6GK-NFN |
| Series | R64G |
| Product line | Olympian Plus |
| Regulator type | General purpose |
| Relieving function | Non-relieving |
| Adjustment | Knob |
| Adjusting knob | Acetal |
| Port size | G3/4 |
| Gauge port | Rc1/8 |
| Maximum inlet pressure | 17 bar |
| Adjustable outlet pressure | 0.3 to 4 bar |
| Flow | 120 dm³/s |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Body material | Zinc alloy |
| Spring bonnet | Aluminium alloy |
| Seal material | Nitrile rubber (NBR) |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | R64G-6GK-NFN |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
