Olympian Plus general purpose pressure regulator, G1-1/2, 0.4-8 bar, with gauge - Norgren R68G-BGK-RLG

Pressure regulators keep the working pressure constant even when the line pressure varies. The Olympian Plus general purpose pressure regulator Norgren R68G-BGK-RLG regulates the outlet pressure in the range 0.4 to 8 bar and has a body made of aluminium alloy.

Benefits

• Diaphragm and balanced valve give good regulation characteristics
• Non-rising adjusting knob with snap-action lock
• Port size G1-1/2
• Outlet pressure adjustable from 0.4 to 8 bar
• Flow 170 dm³/s
• Temperature range -20 to 65 °C

Applications

Typical installations are production lines, test benches and machines with several pressure levels.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
