Foto folgt: Standard-Druckregler Olympian Plus, 3/4 PTF, 0,4-8 bar, ohne Manometer

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Olympian Plus general purpose pressure regulator, 3/4 PTF, 0.4-8 bar, without gauge - Norgren R68G-6AK-NLN

Name: Olympian Plus general purpose pressure regulator, 3/4 PTF, 0.4-8 bar, without gauge - Norgren R68G-6AK-NLN
Brand: Norgren
SKU: NRG-R68G-6AK-NLN
Price: 561.28 EUR
Availability: InStock

Norgren ✓ Original product Brand new

Keeps the working pressure stable and thereby lowers air consumption. The Olympian Plus general purpose pressure regulator Norgren R68G-6AK-NLN accepts an inlet pressure up to 20 bar and is designed for port 3/4 PTF.

Net

€561.28

excl. VAT

Item NRG-R68G-6AK-NLN

Manufacturer no. R68G-6AK-NLN

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Pressure regulators keep the working pressure constant even when the line pressure varies. The Olympian Plus general purpose pressure regulator Norgren R68G-6AK-NLN has a body made of aluminium alloy and weighs 1.95 kg.

Benefits

Diaphragm and balanced valve give good regulation characteristics
Non-rising adjusting knob with snap-action lock
Port size 3/4 PTF
Outlet pressure adjustable from 0.4 to 8 bar
Flow 150 dm³/s
Temperature range -20 to 80 °C

Applications

The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.

Technical data

Property	Value
Manufacturer part number	Norgren R68G-6AK-NLN
Series	R68G
Product line	Olympian Plus
Regulator type	General purpose
Relieving function	Non-relieving
Adjustment	Knob
Adjusting knob	Acetal
Port size	3/4 PTF
Gauge port	1/8 PTF
Maximum inlet pressure	20 bar
Adjustable outlet pressure	0.4 to 8 bar
Flow	150 dm³/s
Medium	Compressed air
Temperature range	-20 to 80 °C
Body material	Aluminium alloy
Spring bonnet	Aluminium alloy
Seal material	Nitrile rubber (NBR)
Height	197 mm
Width	108 mm
Length	190 mm
Weight	1.95 kg
Country of origin	Czechia
RoHS	Compliant
REACH	SVHC substance not present
WEEE	Non-WEEE
Manufacturer	Norgren
Hersteller-Nr	R68G-6AK-NLN
Zolltarifnummer	84811099
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
