Olympian Plus filter/regulator, Without yoke, 5 µm, 0.3-4 bar, manual drain - Norgren B68G-NNK-MR1-RFN

Norgren B68G-NNK-MR1-RFN filters compressed air at 5 µm and regulates it without yoke into the range 0.3 to 4 bar.

Benefits

• High efficiency water removal
• Good regulation characteristics over the flow range
• Non-rising adjusting knob with snap-action lock
• Filtration grade 5 µm with an element made of sintered plastic
• Inlet pressure up to 17 bar, outlet pressure adjustable from 0.3 to 4 bar
• Flow 240 dm³/s in the temperature range -20 to 80 °C

Applications

The unit is built into production lines, packaging machines and test benches where compressed air up to 17 bar is regulated to 0.3 to 4 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The regulator type is general purpose and works relieving. The temperature range is -20 to 80 °C.
