Olympian Plus filter/regulator, G1-1/2, 5 µm, 0.7-17 bar, automatic drain - Norgren B68G-BGT-AR1-RSN

The Olympian Plus filter/regulator Norgren B68G-BGT-AR1-RSN combines filter and regulator in one unit and holds the outlet pressure in the range 0.7 to 17 bar.

Benefits

• High efficiency water removal
• Good regulation characteristics over the flow range
• T-bar adjustment
• Filtration grade 5 µm with an element made of sintered plastic
• Inlet pressure up to 17 bar, outlet pressure adjustable from 0.7 to 17 bar
• Flow 240 dm³/s in the temperature range -20 to 80 °C

Applications

The filter/regulator sits at the start of the air preparation ahead of valve islands, cylinders and tools that need clean air at 0.7 to 17 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The regulator type is general purpose and works relieving. The temperature range is -20 to 80 °C.
