Olympian Plus coalescing filter, without yoke, 0.01µm, manual drain - Norgren F68H-NNN-MU0
Protects valves and cylinders from dirt and extends their service life. The Olympian Plus coalescing filter Norgren F68H-NNN-MU0 accepts an inlet pressure up to 17 bar and weighs 1.78 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Compressed air filters keep water, particles and oil away from the downstream equipment. The Olympian Plus coalescing filter Norgren F68H-NNN-MU0 seals with nitrile rubber (nbr) and is designed for port Without yoke.
Benefits
- High flow coalescing filter with efficient oil and particle removal
- The service indicator turns from green to red when the element must be replaced
- Port size Without yoke
- Flow 60 dm³/s
- Filtration grade 0.01 µm
- Temperature range -20 to 65 °C
Applications
Typical installations are production lines, packaging machines and test benches.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren F68H-NNN-MU0 |
| Series | F68H |
| Product line | Olympian Plus |
| Port size | Without yoke |
| Maximum inlet pressure | 17 bar |
| Flow | 60 dm³/s |
| Filtration grade | 0.01 µm |
| Filter element | Synthetic fibre, Polyurethane (PU) |
| Drain | Manual |
| Bowl material | Aluminium alloy |
| Bowl type | Metal with liquid level indicator |
| Medium | Compressed air |
| Temperature range | -20 to 65 °C |
| Body material | Aluminium alloy |
| Seal material | Nitrile rubber (NBR) |
| Height | 297 mm |
| Width | 108 mm |
| Length | 108 mm |
| Weight | 1.78 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | F68H-NNN-MU0 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
