Inline vacuum filter, grade of filtration 40 µm, tubing O.D. 8 mm OAFA-C-Q8-E-E - Festo 8212644
With a 40 µm grade of filtration, the inline filter OAFA-C-Q8-E-E traps dirt in the vacuum line before it reaches the vacuum generator or valves. Inline installation for tubing O.D. 8 mm, operating pressure -1 to 10 bar. Suitable for battery production (F1a).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
40 µm grade of filtration for 8 mm tubing O.D.: the inline filter OAFA-C-Q8-E-E sits directly in the vacuum line between suction cup and vacuum generator.
Benefits
- Grade of filtration 40 µm, filter element made of PE
- Operating pressure -1 to 10 bar, for vacuum and positive pressure
- Inline installation for tubing O.D. 8 mm, nominal size 8 mm
- LABS (PWIS) conformity VDMA24364 zone III
- Suitable for battery production with reduced Cu/Zn/Ni values (F1a)
- Housing made of PA, seals made of HNBR, RoHS-compliant
Applications
The filter OAFA-C-Q8-E-E suits vacuum circuits in handling and assembly where dust or abrasion can be drawn in. Ambient temperature 0 to 60 °C. Do not clean the housing of the OAFA-C-Q8-E-E with polar solvents such as alcohol.
Technical data
| Feature | Value |
|---|---|
| Type | OAFA-C-Q8-E-E |
| Festo part number | 8212644 |
| Nominal size | 8 mm |
| Instructions on use | The housing should not be cleaned with polar solvents (such as alcohol). |
| Mounting position | Any |
| Grade of filtration | 40 µm |
| Operating pressure | -1 to 10 bar |
| Operating medium | Air |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Suitability for the production of Li-ion batteries | Suitable for battery production with reduced Cu/Zn/Ni values (F1a) |
| Ambient temperature | 0 to 60 °C |
| Type of mounting | Inline installation |
| Pneumatic connection | For tubing O.D. 8 mm |
| Note on materials | RoHS-compliant |
| Material seals | HNBR |
| Material filter | PE |
| Material housing | PA |
| Weight | 24 g |
| Manufacturer | Festo |
| Hersteller-Nr | OAFA-C-Q8-E-E |
| EAN | 4052568906214 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| For hose OD [mm] | 8 |
| Nominal size DN [mm] | 8 |
| Seal material | HNBR |
| Housing material | PA |
| Medium | Air |
| Filter grade [µm] | 40 |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | 0-60 °C |
